  • Asrock B450M-HDV R.40, AMD B450, AM4, Micro ATX, 2 DDR4, VGA, DVI, HDMI, M.2

  • SKU: B450M-HDV R4.0
  • EAN: 4717677336207
  • Motherboard Type: Desktop
  • Socket: AM4
  • Chipset: AMD B450
  • Maximum Memory: 32GB
  • Integrated AMD Radeon
  • 3 Years Warranty
$90.98
  • SHARE:
  •
  •
  •
  •   TrustPilot
WHY BUY WITH SAFEPCDIRECT ?
Certificate 1
Certificate 2
Certificate 3
Certificate 4

 Product Details :

Motherboard Type
Desktop
SocketAM4
ChipsetAMD B450
Maximum Memory32GB DDR4
RAM Speed

3200+(OC)/2933/2667

2400/2133 MHz

Memory TypeDDR4 (Dual Channel)
Storage4 x SATA III
1 x Ultra M.2 2242/2260/2280 - SATA & PCIe
Graphics

Integrated AMD Radeon Vega Series Graphics

in Ryzen Series APU

Graphics Port1 x VGA
1 x DVI-D
1 x HDMI
Audio
7.1 CH HD Audio (Realtek ALC887 Audio Codec)
USB Port Supported6 x USB 3.1 , 6 x USB 2.0 ,
Internal I/O connectors1 x Print Port
1 x COM Port
1 x TPM
1 x Chassis Intrusion and Speaker
1 x CPU Fan
1 x Chassis Fan
1 x Chassis/Water Pump Fan
1 x 24 pin ATX
1 x 4 pin 12V
1 x Front Audio
2 x USB 2.0
1 x USB 3.1 Gen1
Back Panel I/o Ports1 x PS/2 Mouse/Keyboard
1 x D-Sub
1 x DVI-D
1 x HDMI
2 x USB 2.0
4 x USB 3.1 Gen1
1 x RJ-45 LAN
HD Audio Jacks
PCL Express
Ryzen CPUs (Summit & Pinnacle Ridge):
1 x PCIe 3.0 x16

Ryzen CPUs (Raven Ridge):
1 x PCIe 3.0 x16
1 x PCIe 2.0 x1
LANGB LAN
AccessoriesQuick Installation Guide
Support CD
I/O Shield
2 x SATA Data Cables
1 x Screw for M.2 Socket
Package Weight0.8000 kg
Warranty3 Years
Condition New
  • AMD AM4 Socket
  • Supports DDR4 3200+ (OC)
  • 1 PCIe 3.0 x16, 1 PCIe 2.0 x1
  • Graphics Output: HDMI, DVI-D, D-Sub
  • Supports Triple Monitor
  • 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps
  • 4 SATA3, 1 Ultra M.2 (PCIe Gen3 x4 & SATA3)
  • 6 USB 3.1 Gen1 (2 Front, 4 Rear)
  • Realtek Gigabit LAN


AMD StoreMI Technology

A powerful tool that combines the speed of your SSD with the capacity of your hard disk into a single, fast, easy-to-manage drive. SSDs are fast, but expensive, and offer minimal capacity. Mechanical hard drives boast large capacity for a low price, but are much slower than an SSD. AMD StoreMI technology “combines” these two types of storage into a single drive and automatically moves the data you access the most to the SSD, so you get the best of both worlds: SSD responsiveness, and mechanical hard disk capacity. You can also use up to 2GB of RAM as a last-level cache for ultra-fast data.

Ultra M.2 32 Gb/s (PCIe Gen3 x4 & SATA3)

The PCIe Gen3 x4 Ultra M.2 interface pushes data transfer speeds up to 32Gb/s. In addition, it also supports SATA3 6Gb/s M.2 modules, and is compatible with ASRock’s U.2 Kit for installing some of the world’s fastest U.2 PCIe Gen3 x4 SSDs.


High Density Glass Fabric PCB

High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.


Sapphire Black PCB

Pure black PCB appearance. The new Sapphire Black PCB represents rock-solid quality and gives the motherboard a more mysterious touch.


Triple Monitor

Graphics, graphics and even more graphics! You've demanded for more eye candy, so this motherboard supports Triple Monitor. You may choose up to three display interfaces from the rear i/o to connect monitors and use them simultaneously without installing another graphics card.
*Supported with processors with integrated graphics only.

4K x 2K

Composed by a minimum of 3840 x 2160 pixels, which is twice the horizontal and vertical resolution of the 1080p format.
*Supported with A-Series APUs only.

Solid Capacitor Design

ASRock applied solid capacitors on this motherboard. With these solid caps, this motherboard is allowed to perform more stably and ensure longer lifetime.

ELNA Audio Caps

Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream and entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3uA. This is the key to reduce noise level significantly and satisfy even the pickiest audiophiles.

Digi Power

Unlike traditional motherboards that use analog power, this motherboard uses a next generation digital PWM (Pulse-Width Modulation) design, which provides CPU Vcore voltage more efficiently and smoothly, so that the stability and lifespan of the motherboard is greatly enhanced.


A-Tuning

A-Tuning is ASRock's multi purpose software suite with a new interface, more new features and improved utilities.

Full Spike Protection

Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.
ManufacturerAsrock
ColorNo
Graphics ProcessorAMD
Motherboard Form FactorMicro ATX
ChipsetAMD B450
Motherboard TypeDesktop
Maximum Memory32GB
Processor SocketSocket AM4
RAM TechnologyDDR4 (Dual Channel)
RAM Slots2 X DIMM
ConditionBrand New
RefurbishedNo
