Product Details:
Type
| Desktop |
| Socket | AM4 |
| Chipset | AMD X570 |
| Maximum Memory | 128GB |
RAM Speed
| AMD Ryzen series CPUs (Matisse)
4066+(OC)/3466(OC)/3200/2933/2667/2400/2133 AMD Ryzen series CPUs (Picasso)
3466+(OC)/3200(OC)/2933/ 2667/2400/2133 |
| Memory Type | DDR4 (Dual Channel) |
| Storage | 6 x SATA III
1 x M.2 (2242/2260/2280) - SATA & PCIe
1 x M.2 (2242/2260/2280/22110) - SATA & PCIe |
| PCI Express | Ryzen 3rd Gen CPUs:
1 x PCIe 4.0 x16 (x16 mode)
Ryzen 2nd Gen CPUs:
1 x PCIe 3.0 x16 (x16 mode)
Ryzen 1st/2nd Gen CPUs:
1 x PCIe 3.0 x16 (x8 mode)
AMD X570 chipset
1 x PCIe 4.0 x16 (max at x4 mode)
3 x PCIe 4.0 x1 |
| Graphics | MD Radeon Vega Series Graphics in Ryzen Series APU |
| Multi GPU Supports | Supports AMD 2-Way CrossFireX Technology |
| Graphics Port | 1 x HDMI
1 x DisplayPort USB 1.2 |
Audio
| Realtek S1200A 8-Channel High Definition Audio CODEC |
| USB Port Supports | USB 3.2 Gen2 Type-A
4 x USB 3.2 Gen1,7 x USB 2.0 |
| Internal I/O connectors | 2 x Aura RGB Strip
1 x Addressable Gen 2
2 x USB 2.0
2 x M.2 Socket 3
1 x SPI TPM
1 x COM port
6 x SATA 6Gb/s
1 x CPU Fan
3 x Chassis Fan
1 x PCH_FAN
1 x AIO_PUMP
1 x S/PDIF out
1 x 24-pin EATX
1 x 8-pin ATX 12V
1 x 4-pin ATX 12V
1 x Front audio connector(s) (AAFP)
1 x System panel
1 x Clear CMOS jumper
2 x USB 3.2 Gen 1 |
| Back Panel I/o Ports | 1 x PS/2 keyboard/mouse
1 x HDMI
1 x LAN (RJ45)
2 x USB 2.0
3 x Audio jacks
2 x USB 3.2 Gen 1 Type-A
4 x USB 3.2 Gen 2 Type-A |
| Wireless | Wi-Fi with MU-MIMO 802.11 a/b/g/n/ac
Supports dual frequency band 2.4/5 GHz
Up to 1.73Gbps transfer speed
Bluetooth v5.0 |
| LAN | Dual GB LAN |
| Accessories | User manual
I/O Shield
2 x SATA 6Gb/s cable(s)
1 x M.2 Screw Package
1 x Supporting DVD
1 x Extension cable for Addressable LED |
| Package Weight | 1.300 kg |
| Warranty | 3 Years |
| Condition | New |
Foundation of your build
Hosting the latest Ryzen processor with increased number of cores and bandwidth, the Prime X570 series is ready for action with stable power, intuitive cooling and flexible transfer options. It provides all the fundamentals to increase your everyday productivity.
Power delivery enhancements and ProCool connector
The latest AMD Ryzen 3rd Gen processors boosts more core and bandwidth, demanding more juice than typical desktop CPUs. Prime X570-P offers stable power. It augments the motherboard's link to the PSU with eight plus four-pin connectors that pass 12V power directly to the processors. Based on our ProCool design, these jacks use solid pins that can handle more current than hollow-pin connectors.
Tune it your way
The Prime X570 series feature software and firmware controls that make performance accessible to anyone. Prime X570 series also include options allowing you to personalise your build, and helping you to tune your rig to perform the way you want it.
Armoury Crate
Armoury Crate is a new software utility designed to give you centralised control of supported products. From a single intuitive interface, Armoury Crate allows you easily customise RGB lighting and effects for every compatible device in your arsenal. The software also provides control of settings for ASUS product, including keyboard and mouse preferences. Armoury Crate even features dedicated product registration and highlight to help you stay in touch with the ASUS community.
Aura Sync RGB headers
A well-tuned enthusiast system deserves a matching aesthetic. ASUS Aura Sync offers full lighting connected via the motherboard's RGB headers, with a variety of functional presets for external LED strips.* And it can all be synced with an ever-growing portfolio of Aura-capable ASUS hardware.
Addressable RGB LED strip Gen 2 header
The Prime X570-P now has the upgraded, addressable RGB header that allows intuitive software to control individual LEDs for more advanced effects and plenty of personalisation. The header is also ready for next-generation lighting devices, which can detect how many addressable LEDs are on an attached device, simplifying the setup process and allowing for automatically configured lighting effects.
Brighten Up Your Build
Built-in LED lighting options illuminate your build in a variety of eye-catching styles.
- Enhanced power solution: Components provide better power efficiency
- Industry-leading cooling options: Comprehensive controls for fans and AIO pump, via Fan Xpert 4 or the acclaimed UEFI
- ASUS OptiMem: Careful routing of traces and vias to preserve signal integrity for improved memory overclocking
- Next-gen connectivity: Supreme flexibility with PCIe Gen 4 support, dual M.2 support, USB 3.2 Gen 2 ports
- Aura Sync RGB header: Synchronise RGB header with a vast portfolio of compatible PC gear, including next-gen addressable RGB strips
