Product Details
Type
| Server / Workstation |
| Socket | 3647 |
Chip Set
| Intel C621 |
| Maximum Memory | 1536GB 12 x DIMM |
| RAM Speed | 933/2666/2400 MHz - RDIMM , LR-DIMM |
| Memory Type | DDR4 (Dual Channel) |
| Storage | 10 x SATA III
4 x U.2
1 x M.2 (2242/2260/2280/22110) - SATA & PCIe |
| Graphics | Integrated Intel HD Graphics |
| Multi GPU Support | Supports NVIDIA 3-Way SLI Technology
Supports AMD 3-Way CrossFireX™ Technology |
| Graphics Port | 1 x HDMI
1 x DisplayPort 1.2 |
| Audio | Realtek S1220A 7.1-Channel High Definition Audio CODEC |
| USB Ports | 2 x USB 3.1 Gen 2 , 8 x USB 3.1 Gen 1 ,6 x USB 3.1 Gen 1 |
| Internal I/O connectors | 2 x USB 3.1 Gen 1
1 x USB 2.0
1 x M.2 Socket 3
1 x TPM
1 x COM port
10 x SATA 6Gb/s
1 x VROC_HW_Key
2 x CPU Fan
7 x Chassis Fan
2 x 8-pin EATX 12V
1 x 24-pin EATX
1 x VGA connector
1 x Front audio
1 x AUX panel
1 x SMBus
1 x 6-pin EATX 12V_3
1 x System panel
4 x U.2 |
| Back Panel I/o Ports | 1 x PS/2 keyboard/mouse
2 x LAN (RJ45)
2 x USB 3.1 Gen 2
4 x USB 3.1 Gen 1
4 x USB 2.0
1 x Optical S/PDIF out
1 x USB BIOS Flashback Button
1 x 8-channel Audio I/O |
| LAN | Dual GB LAN |
| Accessories | 1 x Vertical M.2 bracket set
I/O Shield
1 x COM port cable
6 x SATA cables
2 x M.2 screws
1 x 3-Way SLI bridge
1 x SLI bridge
1 x Q-Connector
1 x 2-port USB module
1 x Extension Cable for RGB strips (80 cm) |
PCL Express
| 3 x PCIe 3.0 x16 (x16 mode)
2 x PCIe 3.0 x16 (Single at x16dual at x8/x8), 2 x PCIe 3.0 x16 (x8 mode) |
| Package Weight | 2.3550kg |
| Warranty | Years |
| Condition | New |
- Up to 4-Way NVIDIA® SLI® and AMD® Crossfire X™ on demand
- Two-way Xeon® CPU OC tuning for extreme performance
- Superb scalability and connectivity with onboard U.2, M.2, and USB 3.1 Type-C and Type-A
- Built with premium components for excellent power efficiency
- Easy Management and maintenance with ASUS Control Center (ACC) management software and USB BIOS Flashbac
Up to 4-way multiple-graphic cards
The Intel® C621 chipset-based dual socket workstation motherboard features on-demand NVIDIA® SLI™ and AMD® CrossFireX™ technology.
ASUS WS C621E SAGE accommodates up to four dual-width graphic cards with a four true PCIe Gen3 x16 link to unleash maximum graphic performance. With support for up to 4-way NVIDIA® SLI™, AMD CrossFireX™, and 2-Way NVIDIA Quadro® SLI™, WS C621E SAGE is an excellent choice for content creators, mechanical or architectural engineers, and anyone with processing-intensive workloads.
Extraordinary performance with dual Intel® Xeon® CPU overclocking
Dual Intel® Xeon® CPU overclocking, pushes the power processing power beyond the extreme
ASUS WS C621E SAGE breaks performance barriers, giving you the capability to overclock dual Xeon® CPUs. With its unique BIOS mechanism dedicated to boosting CPU performance, WS C621E SAGE can deliver incredible system speed.
Supporting up to 12 DDR4 Error-correcting code memory (ECC Memory)
Keeps your system running at a brisk pace, even when running multiple hardware-intensive programs! ASUS WS C621E SAGE supports up to 12 DDR4 error-correcting code (ECC) memory to ensure fast and responsive system performance, even when running multiple RAM-intensive applications — such as video, audio and image editing applications - simultaneously.
Lightning-fast storage speed with NVMe PCIe SSD RAID 0 support
With support for multiple NVMe PCIe storage devices configured as a RAID 0 array, ASUS WS C621E SAGE lets you enjoy lightning-fast data transfers that are far beyond those provided by single drives.
Super-fast transfers at up to 32Gbps with onboard four U.2 and M.2
ASUS WS C621E SAGE is built with onboard M.2 and U.2 connectors to fit both 2.5-inch NVMe and M.2 SSDs. By using the maximum PCIe Gen3.0 x4 bandwidth of 32Gbps, WS C621E SAGE enables data transfer speeds that are up to 5.3X faster than traditional storage devices.
10Gb/s USB 3.1 Gen2 onboard
With backward-compatible USB 3.1 Gen2 Type-A and reversible USB 3.1 Gen2 Type-C ports, you'll experience ultimate connection flexibility and data-transfer speeds of up to 10Gb/s - twice as fast as USB 3.0 or USB 3.1 Gen1.
Exclusive audio features with Realtek® codec and unique design features for pristine and powerful audio
Not satisfied with a single storage device read/write speeds? Then join the fast lane and build a RAID 0 array using NVMe PCIe storage drives to enjoy data transfers at lightning speeds!
ASUS WS C621E SAGE has a unique audio codec designed in close collaboration with Realtek®. The Realtek® S1220A features an unprecedented 120dB signal-to-noise ratio for the stereo line-out and an 113dB SNR for the line-in, providing pristine audio quality
Offers 3D surround-sound technology for incredibly rich audio with all types of headphones.
