Fractal Design Define Nano S (Black Window) Quiet PC Case w/ Clear Window, Mini ITX, 2 Fans, ATX PSU & 315mm GPU Support, 280mm Watercooling, Up to 4 HDD/SSD

  1. Home
  2. Components
  3. Fractal Design Define Nano S (Black Window) Quiet PC Case w/ Clear Window, Mini ITX, 2 Fans, ATX PSU & 315mm GPU Support, 280mm Watercooling, Up to 4 HDD/SSD

  • Fractal Design Define Nano S (Black Window) Quiet PC Case w/ Clear Window, Mini ITX, 2 Fans, ATX PSU & 315mm GPU Support, 280mm Watercooling, Up to 4 HDD/SSD

  • SKU: FD-CA-DEF-NANO-S-BK
  • EAN: 7350041084136
  • Form Factor: Mini ITX
  • Power Supply Wattage: No PSU
  • Motherboard Support :Mini ITX
  • Expansion Slots : 2 Expansion slots
  • 1 Years warranty
$101.09
Out of Stock
    • SHARE:
    •
    •
    •
    •   TrustPilot
    WHY BUY WITH SAFEPCDIRECT ?
    Certificate 1
    Certificate 2
    Certificate 3
    Certificate 4

    Related Products

    Product Details

    Form FactorMini ITX
    Power Supply Wattage
    		No PSU
    Motherboard Support
    		Mini ITX
    Connectors / Controls2 x USB 3.0
    Audio in/out
    Power button with LED (blue)
    HDD activity LED (blue)
    Reset button
    Drive Bays2 x 3.5" HDD/2.5" SSD positions
    2 x 2.5" dedicated SSD unit positions (up to 13 mm thick)
    Expansion Slots
    		2 Expansion slots
    Cooling System
    Included
    Front: 1 x Dynamic GP14 140 mm fan
    Rear: 1 x Dynamic GP12 120 mm fan

    Fan Mounts
    Front: 2 x 120 / 140 mm
    Top: 2 x 120 / 140 mm
    Rear: 1 x 120 mm
    Bottom: 1 x 120 mm


    Water Cooling options:
    Front: 120/240 mm or 140/280 mm (max width 147 mm, max length 312 mm; some radiators extend beyond the screw holes)

    Top: 120/240 mm (max component height on motherboard 35 mm. Big heat sinks on RAM or power regulators around CPU could conflict with this restriction.)

    Rear: 120 mm (max width 125 mm; some radiators extend beyond the screw holes)

    Bottom: 120 mm (max thickness and length: 85 mm x 160 mm)
    CompatablityGFX Card:
    315 mm with front fans mounted (cards wider than the dual slot bracket are not recommended)
    Max recommended GPU thickness: 39 mm

    Max CPU Cooler:
    162 mm

    PSU:
    ATX
    Max length: 160 mm
    ColourBlack
    Weight/Dimensions5 kg
    (WxHxD) 203 x 330 x 400 mm
    With feet/protrusions/screws: 203 x 344 x 412 mm
    Volume: 26.8 liters
    Package weight
    5.5000 kg
    Warranty2 year
    ConditionBrand New



    An ITX case that features compatibility with high-end, full-size components, superior sound dampening, and an ATX-like layout


    • Define Series hallmarks in the ITX form factor: sound dampening plus ModuVent™ technology
    • User-friendly design with an ATX style layout and full-size component compatibility
    • Good storage options for its size: up to 4 drives can be installed
    • Multiple cooling setups: room for tower air coolers; includes brackets for pump and reservoir mounting
    • Open interior allows air to pass through unobstructed from the front intake to the back exhaust

    Designed for silent computing

    This case includes two Dynamic Series fans with both bottom and front intakes protected by easy-to-clean, removable dust filters. With its mounting capabilities for simultaneous radiators and unobstructed airflow path, the Define Nano S can cool enthusiast-level components.

    Equipped with Fractal Design’s signature ModuVent™ technology on the top vents and sound dampening throughout, the Define Nano S can run a powerful system quietly, a hallmark of the Define series.


    Key features

    • User-friendly construction compatible with full-size components and with superior cable management
    • Flexible storage options with room for up to four drives
    • Accommodates a variety of radiator sizes and includes brackets for reservoir and pump mounting
    • Features two Dynamic Series fans — 1 GP-12 and 1 GP-14 — with an adapter included for motherboards with limited fan headers
    • Featuring an open interior allowing an unobstructed airflow path from the front of the case to the rear exhaust
    • Easy-to-clean filters on the bottom and front, spanning the PSU position, with the bottom filter ejecting from the front for easy-access
    ManufacturerFractal Design
    ColorBlack
    Drive Bays 3.5"2
    Drive Bays 5.25"Not Specified
    Case Form FactorMini ITX
    Front PortsUSB
    MaterialSteel
    Supported Motherboard TypeMini-ITX (101)
    USB 2.0 Ports Qty2
    ConditionBrand New
    RefurbishedNo
